Chevrolet Uplander I (2004-2008) w/ multimedia system w/o multimedia system Wiring diagrams
This page contains all the electrical diagrams for the component. w/ multimedia system w/o multimedia system, in which he is found in the car Chevrolet Uplander I (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ multimedia system w/o multimedia system wiring diagram (1 of 2)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BRN/WHT WIRE
CLASS 2 SERIAL DATA
DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH, TO LEFT OF STEERING COLUMN)
DIGITAL RADIO RECEIVER (BEHIND LEFT SIDE OF DASH)
DIGITAL VIDEO DISC (DVD) PLAYER
DK BLU WIRE
DK GRN WIRE
DRIVER MEMORY SEAT MODULE (UNDER DRIVER SEAT)
ENGINE CONTROL MODULE (ECM) (3.9L)
GMLAN RESISTOR
GRY WIRE
HI SPD GMLAN SERIAL DATA
HOT AT ALL TIMES
HVAC CONTROL MODULE (IN DASH CENTER TRIM PANEL, BENEATH RADIO)
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT DASH ACCESS PANEL)
LEFT SLIDING DOOR MODULE (LSDM) (BEHIND LEFT REAR INTERIOR BODY PANEL)
LT BLU WIRE
LT GRN WIRE
MOBILE ENTERTAINMENT PLAYER MODULE
NCA WIRE
ONSTAR FUSE 6
ORG/ WIRE
PPL
RADIO
RED WIRE
RED/WHT WIRE
RIGHT SLIDING DOOR MODULE (RSDM) (BEHIND RIGHT REAR INTERIOR BODY PANEL)
SPLICE
TAN WIRE
TAN/BLK WIRE
TRANSMISSION CONTROL MODULE (TCM)
W/ MULTIMEDIA SYSTEM
W/ MULTIMEDIA SYSTEM W/O MULTIMEDIA SYSTEM
W/ ONSTAR
W/ SECOND ROW SIDE AIR BAGS
W/ SIDE IMPACT
WHT WIRE
YEL/BLK WIRE
Go to component -> Computer data lines circuit -> W/ MULTIMEDIA SYSTEM W/O MULTIMEDIA SYSTEM
w/ multimedia system w/o multimedia system wiring diagram (2 of 2)
A/T SHIFT LOCK CONTROL SOLENOID
AMBIENT LIGHT SENSOR
AUDIO COUPLING TRANSFORMER
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR ASSEMBLY HVAC CONTROL MODULE
BLUNT CUT)
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CIGAR LIGHTER
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DIGITAL VIDEO DISC (DVD) PLAYER
FRONT AUXILIARY POWER OUTLET
HEADLAMP SWITCH
HVAC CONTROL MODULE
I/P MULTIFUNCTION SWITCH
IGNITION SWITCH
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY
MOBILE ENTERTAINMENT PLAYER MODULE
NCA WIRE
RADIO
REAR WINDOW WASHER FLUID PUMP
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY
STEERING WHEEL)
STOP LAMP RELAY 27
THEFT DETERRENT EXCITER MODULE
THEFT LIGHT EMITTING DIODE (LED)
TURN SIGNAL/ MULTIFUNCTION SWITCH
VEHICLE COMMUNICATION UNIT (VCU)
W/ ACCESSORY STEERING WHEEL CONTROL
W/ DIGITAL RADIO
W/ INTERMITTENT REAR WINDOW WIPER SYSTEM
W/ LATE PRODUCTION
W/ MULTIMEDIA SYSTEM W/O MULTIMEDIA SYSTEM
W/ ONSTAR, NAVIGATION
W/ REAR SEAT ENTERTAINMENT SYSTEM
W/O ACCESSORY STEERING WHEEL CONTROL
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
WPR 2 RELAY
Go to component -> Ground distribution circuit (2 of 4) -> W/ MULTIMEDIA SYSTEM W/O MULTIMEDIA SYSTEM
