Chevrolet Uplander I (2004-2008) toward left horn) Wiring diagram
This page shows the only wiring diagram for the component.toward left horn), which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram toward left horn) (1 of 1)
3.5L
3.9L 3.9L
A/C COMPRESSOR CLUTCH
AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR
AUTOMATIC LEVEL CONTROL (ALC) SENSOR
AUTOMATIC TRANSMISSION IGNITION CONTROL MODULE (ICM)
AUXILIARY BLOWER MOTOR CONTROL MODULE
BATTERY
BLK WIRE
BLUNT CUT)
BODY CONTROL MODULE (BCM)
ELECTRONIC BRAKE CONTROL MODULE
FAN 2 RELAY
FUEL PUMP RELAY DIODE 3
HOOD AJAR SWITCH
INTERNAL MODE SWITCH
LEFT BACKUP LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP
LEFT HIGH BEAM HEADLAMP
LEFT HORN
LEFT LOW BEAM HEADLAMP
LEFT SLIDING DOOR MODULE (LSDM)
LEFT TAIL LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
RIGHT COOLING FAN
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP RIGHT HORN
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TOWARD LEFT HORN)
W/ LEFT POWER SLIDING DOOR
W/ REAR A/C
W/ REMOTE KEYLESS ENTRY
W/ TRAILER PROVISIONS
W/O REAR A/C
WHT WIRE
Go to component: -> Ground distribution circuit (1 of 4) -> TOWARD LEFT HORN)
