Chevrolet Uplander I (2004-2008) theft deterrent exciter module Wiring diagram
This page shows the only wiring diagram for the component.theft deterrent exciter module, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram theft deterrent exciter module (1 of 1)
A/T SHIFT LOCK CONTROL SOLENOID
AMBIENT LIGHT SENSOR
AUDIO COUPLING TRANSFORMER
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR ASSEMBLY HVAC CONTROL MODULE
BLUNT CUT)
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CIGAR LIGHTER
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DIGITAL VIDEO DISC (DVD) PLAYER
FRONT AUXILIARY POWER OUTLET
HEADLAMP SWITCH
HVAC CONTROL MODULE
I/P MULTIFUNCTION SWITCH
IGNITION SWITCH
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY
MOBILE ENTERTAINMENT PLAYER MODULE
NCA WIRE
RADIO
REAR WINDOW WASHER FLUID PUMP
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY
STEERING WHEEL)
STOP LAMP RELAY 27
THEFT DETERRENT EXCITER MODULE
THEFT LIGHT EMITTING DIODE (LED)
TURN SIGNAL/ MULTIFUNCTION SWITCH
VEHICLE COMMUNICATION UNIT (VCU)
W/ ACCESSORY STEERING WHEEL CONTROL
W/ DIGITAL RADIO
W/ INTERMITTENT REAR WINDOW WIPER SYSTEM
W/ LATE PRODUCTION
W/ MULTIMEDIA SYSTEM W/O MULTIMEDIA SYSTEM
W/ ONSTAR, NAVIGATION
W/ REAR SEAT ENTERTAINMENT SYSTEM
W/O ACCESSORY STEERING WHEEL CONTROL
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
WPR 2 RELAY
Go to component: -> Ground distribution circuit (2 of 4) -> THEFT DETERRENT EXCITER MODULE
