Chevrolet Uplander I (2004-2008) switch connector, behind left dash access panel) Wiring diagrams

This page contains all the electrical diagrams for the component. switch connector, behind left dash access panel), in which he is found in the car Chevrolet Uplander I (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram switch connector, behind left dash access panel) (1 of 2)

Wiring diagram switch connector, behind left dash access panel) for Chevrolet Uplander I (2004-2008)

Get access

AIR BAG FUSE 20 AIR BAG IND AIR BAG OFF IND AIR BAG ON IND BLK WIRE BLK/WHT WIRE BRN WIRE CLASS 2 (SDM) CLASS 2 SERIAL DATA PASSENGER SEAT BELT INDICATOR DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH, TO LEFT OF STEERING COLUMN) DK BLU WIRE DK GRN WIRE GRY WIRE HOT W/ IGN MAIN RELAY ENERGIZED ILLUM INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LEFT INFLATABLE RESTRAINT SIDE IMPACT MODULE (IN LEFT FRONT SEAT BACK) LEFT SEAT BELT SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) LOGIC B+ LT BLU WIRE LT GRN WIRE MESSAGE CENTER NCA WIRE ORG/ WIRE PASSENGER SEAT BELT IND PASSENGER SEAT BELT NOT FASTENED PNK IGNITION 1 VOLTAGE WIRE PNK OCCUPANT SERIAL DATA WIRE PNK WIRE POWER IND PPL RIGHT INFLATABLE RESTRAINT SIDE IMPACT MODULE (IN RIGHT FRONT SEAT BACK) RIGHT SEAT BELT SWITCH (IN PASSENGER SEAT BELT BUCKLE ASSEMBLY) SEAT BELT IND SEAT BELT TENS LO REF PPS SENS LO REF SEAT BELT TENS SIG GROUND PPS SENS SIG SHORTING BAR SPLICE PACK SWITCH CONNECTOR, BEHIND LEFT DASH ACCESS PANEL) TAN/WHT WIRE UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL) WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> Supplemental restraints circuit, with second row side air bags (2 of 2) -> SWITCH CONNECTOR, BEHIND LEFT DASH ACCESS PANEL)

Wiring diagram switch connector, behind left dash access panel) (2 of 2)

Wiring diagram switch connector, behind left dash access panel) for Chevrolet Uplander I (2004-2008)

Get access

1361 1361 608 SEAT BELT TENS LO REF PPS SENS LO REF AIR BAG FUSE 20 AIR BAG IND AIR BAG OFF IND AIR BAG ON IND BLK WIRE BLK/WHT WIRE CLASS 2 (SDM) CLASS 2 (SDM) B+ CLASS 2 SERIAL DATA PASSENGER SEAT BELT INDICATOR DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH, TO LEFT OF STEERING COLUMN) DK BLU WIRE DK GRN WIRE GRY WIRE HOT W/ IGN MAIN RELAY ENERGIZED ILLUM INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT SEAT BELT PRETENSIONER (IN DRIVER SEAT BELT RETRACTOR ASSEMBLY) LEFT SEAT BELT SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) LOGIC LT BLU WIRE LT GRN WIRE MESSAGE CENTER NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER SEAT BELT IND PASSENGER SEAT BELT NOT FASTENED PNK 5 6 WIRE PNK 7 8 WIRE PNK IGNITION 1 VOLTAGE WIRE PNK OCCUPANT SERIAL DATA WIRE PNK WIRE POWER IND PPL RIGHT FRONT SEAT BELT PRETENSIONER (IN PASSENGER SEAT BELT RETRACTOR ASSEMBLY) RIGHT SEAT BELT SWITCH (IN PASSENGER SEAT BELT BUCKLE ASSEMBLY) SEAT BELT IND SEAT BELT TENS SIG GROUND PPS SENS SIG SHORTING BAR SPLICE PACK SWITCH CONNECTOR, BEHIND LEFT DASH ACCESS PANEL) TAN/WHT WIRE UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL) YEL WIRE

Go to component: -> Supplemental restraints circuit, with side air bag (2 of 2) -> SWITCH CONNECTOR, BEHIND LEFT DASH ACCESS PANEL)
