Chevrolet Uplander I (2004-2008) passenger outside rearview mirror mirror defogger Wiring diagram
This page shows the only wiring diagram for the component.passenger outside rearview mirror mirror defogger, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger outside rearview mirror mirror defogger (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM)
CLASS 2 DATA
CLASS 2 SERIAL DATA
DEF INDICATOR CONTROL
DEFOGGER REQUEST
DEFOGGER SWITCH
DK GRN WIRE
DRIVER OUTSIDE REARVIEW MIRROR
HOT AT ALL TIMES
HTD/ MIR FUSE 16
HVAC CONTROL MODULE (IN DASH CENTER TRIM PANEL, BENEATH RADIO)
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
IGN
IGN DEFOGGER INDICATOR
LT GRN WIRE
MIRROR DEFOGGER
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR MIRROR DEFOGGER
REAR FOG RELAY CONTROL
REAR WINDOW DEFOGGER GRID
RED WIRE
RR DEFOG FUSE 36
RR DEFOG RELAY 30
SPLICE PACK
UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL)
WHT WIRE
Go to component: -> Defoggers circuit -> PASSENGER OUTSIDE REARVIEW MIRROR MIRROR DEFOGGER
