Chevrolet Uplander I (2004-2008) left sliding door unlatch actuator Wiring diagram
This page shows the only wiring diagram for the component.left sliding door unlatch actuator, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left sliding door unlatch actuator (1 of 1)
A/T W/ OVER DRIVE
ACCESSORY AC/DC POWER CONTROL MODULE
BLK WIRE
DIFFERENTIAL CLUTCH PUMP ACTUATOR VALVE CHECK
DRIVER DOOR KEY SWITCH
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER WINDOW SWITCH
FUEL PUMP
FUEL PUMP, SENDER ASSEMBLY
LEFT DOOR CONTACT PLATE
LEFT LICENSE LAMP
LEFT SEAT BELT SWITCH
LEFT SLIDING DOOR DETENT SWITCH
LEFT SLIDING DOOR JAMB SWITCH BODY CONTROL MODULE (BCM)
LEFT SLIDING DOOR OPEN/ CLOSE SWITCH
LEFT SLIDING DOOR UNLATCH ACTUATOR
LIFTGATE DOOR JAMB SWITCH
MANUAL SEAT POWER SEAT
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
REAR AUXILIARY POWER OUTLET
REAR WINDOW DEFOGGER GRID
RIGHT BACKUP LAMP
RIGHT LICENSE LAMP
RIGHT SLIDING DOOR MODULE (RSDM) REAR WINDOW WIPER MOTOR
RIGHT TAIL LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
SLIDING DOOR MODULE)
W/ LEFT POWER SLIDING DOOR
W/ REAR SEAT ELECTRICAL RECEPTACLE, RIGHT POWER SLIDING DOOR
W/ REAR SEAT ELECTRICAL RECEPTACLE, W/O RIGHT POWER SLIDING DOOR
W/ RIGHT POWER SLIDING DOOR
Go to component -> Ground distribution circuit (3 of 4) -> LEFT SLIDING DOOR UNLATCH ACTUATOR
