Chevrolet Uplander I (2004-2008) left sliding door clutch ctrl left sliding door mtr close ctrl Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 LEFT SLIDING DOOR MTR OPEN CTRL 1 2 3 4 5 6 7 8 9 10 11 12 13 14 RIGHT SLIDING DOOR MTR OPEN CTRL BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CABLE MOTOR CLASS 2 SERIAL DATA CLUTCH COMPUTER DATA LINES SYSTEM DK GRN WIRE GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) LEFT SLDG DOOR OPEN/CLOSE SW SIG BATTERY POSITIVE VOLTAGE LEFT SLIDING DOOR CLUTCH CTRL LEFT SLIDING DOOR MTR CLOSE CTRL LEFT SLIDING DOOR LATCH MTR CTRL LEFT SLIDING DOOR DETENT SW SIG LEFT SLIDING DOOR MODULE (LSDM) (BEHIND LEFT REAR INTERIOR BODY PANEL) LEFT SLIDING DOOR MOTOR ASSEMBLY LEFT SLIDING DOOR OPEN/ CLOSE SWITCH (ON LEFT "B" PILLAR) LH-PSD FUSE 24 LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE POSITION SENSOR PSD FUSE 21 RED WIRE RED/BLK WIRE RED/WHT WIRE RH-PSD FUSE 25 RIGHT SLDG DOOR OPEN/CLOSE SW SIG BATTERY POSITIVE VOLTAGE RIGHT SLIDING DOOR CLUTCH CTRL RIGHT SLIDING DOOR MTR CLOSE CTRL RIGHT SLIDING DOOR MODULE (RSDM) (BEHIND RIGHT REAR INTERIOR BODY PANEL) RIGHT SLIDING DOOR OPEN/ CLOSE SWITCH TAN WIRE TAN/WHT WIRE WHT WIRE YEL WIRE
