Chevrolet Uplander I (2004-2008) l side impact sig r side impact sig r side impact vol l side impact vol Wiring diagram

This page shows the only wiring diagram for the component.l side impact sig r side impact sig r side impact vol l side impact vol, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram l side impact sig r side impact sig r side impact vol l side impact vol (1 of 1)

Wiring diagram l side impact sig r side impact sig r side impact vol l side impact vol for Chevrolet Uplander I (2004-2008)

Get access

BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GROUND GRY WIRE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (IN STEERING COLUMN) L SIDE IMPACT SIG R SIDE IMPACT SIG R SIDE IMPACT VOL L SIDE IMPACT VOL LEFT INFLATABLE RESTRAINT FRONT END SENSOR (ON LEFT RADIATOR SUPPORT) LEFT INFLATABLE RESTRAINT SIDE IMPACT SENSING MODULE (SISM) (IN LEFT "B" PILLAR) LEFT REAR INFLATABLE RESTRAINT SIDE IMPACT MODULE LOW REF LOW REF R DISCRIMINATING SENS SIG L DISCRIMINATING SENS SIG LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL RIGHT INFLATABLE RESTRAINT FRONT END SENSOR (ON RIGHT RADIATOR SUPPORT) RIGHT REAR INFLATABLE RESTRAINT SIDE IMPACT MODULE SHORTING BAR TAN WIRE TAN/BLK WIRE TAN/ORG WIRE TAN/WHT WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component: -> Supplemental restraints circuit, with second row side air bags (1 of 2) -> L SIDE IMPACT SIG R SIDE IMPACT SIG R SIDE IMPACT VOL L SIDE IMPACT VOL
