Chevrolet Uplander I (2004-2008) l aud sig + r aud sig + Wiring diagram

This page shows the only wiring diagram for the component.l aud sig + r aud sig +, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram l aud sig + r aud sig + (1 of 1)

Wiring diagram l aud sig + r aud sig + for Chevrolet Uplander I (2004-2008)

Get access

351 372 GROUND AUD COMMON DRAIN WIRE 5072 640 SERIAL DATA BATTERY 9 10 11 2 AUDIO COMMON R AUDIO SIG (+) L AUDIO SIG (+) GROUND AUDIO COMMON BARE BARE DRAIN WIRE BLK WIRE BLK/WHT WIRE BLUNT CUT) BRN/WHT WIRE COAX COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA DIGITAL RADIO RECEIVER (BEHIND LEFT SIDE OF DASH) DIGITAL VIDEO DISC (DVD) PLAYER (IF EQUIPPED) DK GRN/WHT WIRE HOT AT ALL TIMES I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) L AUD SIG + R AUD SIG + L AUDIO SIG (+) NCA WIRE ORG/ WIRE R AUDIO SIG (+) RADIO RED WIRE RED/WHT WIRE RFA MDLS FUSE 7 SATELLITE IN SERIAL DATA TAN WIRE TAN/WHT WIRE WHT WIRE

Go to component: -> Satellite radio circuit -> L AUD SIG + R AUD SIG +
