Chevrolet Uplander I (2004-2008) i/p multi-function switch Wiring diagrams
This page contains all the electrical diagrams for the component. i/p multi-function switch, in which he is found in the car Chevrolet Uplander I (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram i/p multi-function switch (1 of 2)
B+ IPC
BACK-UP LAMP CIRCUIT
BLK WIRE
BLK/WHT WIRE
BLUNT CUT (W/ TRAILER PROVISION)
BRN WIRE
CLUSTER/ HVAC FUSE 8
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
ELC FUSE 15
GROUND
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
I/P MULTI-FUNCTION SWITCH
INSTRUMENT PANEL CLUSTER MESSAGE CENTER
IPC
IPC CLASS 2 DATA
LEFT BACK-UP LAMP
LEFT LICENSE LAMP
LEFT TAIL LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
LEFT TURN SIG IND
LOGIC
LT GRN WIRE
PPL
PPL PPL
RED WIRE
RED/WHT WIRE
RIGHT BACK-UP LAMP RIGHT TAIL LAMP
RIGHT LICENSE LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
RIGHT TURN SIG IND
TAN WIRE
W/ REAR A/C
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> I/P MULTI-FUNCTION SWITCH
Wiring diagram i/p multi-function switch (2 of 2)
