Chevrolet Uplander I (2004-2008) horn relay Wiring diagrams
This page contains all the electrical diagrams for the component. horn relay, in which he is found in the car Chevrolet Uplander I (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
horn relay wiring diagram (1 of 2)
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
DK GRN WIRE
FRONT WHEELWELL)
HORN FUSE 7
HORN RELAY
HORN RELAY CTRL
HORN SWITCH
HOT AT ALL TIMES
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT HORN
NCA WIRE
RIGHT HORN
STEERING WHEEL)
TAN WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT
W/ ELECTRONIC CRUISE
W/O ELECTRONIC CRUISE
WHT WIRE
Go to component -> Horn circuit -> HORN RELAY
horn relay wiring diagram (2 of 2)
12 VOLT REFERENCE
3.5L
A/C CLTCH RELAY
ABS MOTOR FUSE
AC CLTCH FUSE
BATT MAIN 1 FUSE
BATT MAIN 2 FUSE
BATT MAIN 3 FUSE
BATTERY STARTER MOTOR
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR ASSEMBLY
BODY CONTROL MODULE (BCM) IGNITION 3 VOLTAGE
BRN WIRE
CRANK VOLTAGE
CRNK RELAY
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
FAN 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FAN-2 FUSE
FROM BATT MAIN 3 FUSE (DIAGRAM 1 OF 4)
FROM HORN FUSE (DIAGRAM 1 OF 4)
FRT BLWR HI FUSE
FRT WIPER FUSE
FRT WSW FUSE
FUEL PUMP FUSE
FUEL PUMP RELAY
FUSIBLE LINK 2 (8 GA-
FUSIBLE LINK 242 (2 GA-
GENERATOR
GRY/WHT WIRE
HI BEAM RELAY
HORN FUSE
HORN RELAY
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
IGNITION 1 VOLTAGE
IGNITION SWITCH
LO BEAM RELAY
LOCK
PCM ETC FUSE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWR/TRN RELAY
RED WIRE
RR DEFOG FUSE
RR DEFOG RELAY 30
RUN RLY RELAY
RUN WIRE
STRTR SOL FUSE
TO 115 VAC AUXILIARY POWER OUTLET (DIAGRAM 2 OF 4)
TO FAN 1 FUSE (DIAGRAM 1 OF 4)
TO I/P FUSE BLOCK (DIAGRAM 3 OF 4)
TO I/P FUSE BLOCK (DIAGRAM 4 OF 4)
TOWARD RIGHT SIDE OF DASH)
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL)
W/ AUXILIARY POWER OUTLET
WHT WIRE
WPR 1 RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> HORN RELAY
