Chevrolet Uplander I (2004-2008) high req low req low ref Wiring diagram
This page shows the only wiring diagram for the component.high req low req low ref, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high req low req low ref (1 of 1)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BRN WIRE
CLASS 2 SERIAL DATA
DATA LINK CONNECTOR (DLC) (BELOW LEFT SIDE OF DASH, TO LEFT OF STEERING COLUMN)
DK BLU WIRE
DRIVER BACK HEATED SEAT ELEMENT (BEHIND UPHOLSTERY IN SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT (UNDER UPHOLSTERY IN SEAT CUSHION)
DRIVER HEATED SEAT HIGH INDICATOR
DRIVER HEATED SEAT LOW INDICATOR
DRIVER HEATED SEAT RELAY (UNDER
DRIVER HEATED SEAT SWITCH
DRIVER SEAT
GRY WIRE
GRY/RED WIRE
HEATED SEAT ELEMENT
HEATED SEAT THERMISTOR
HIGH REQ LOGIC
HIGH REQ LOW REQ LOW REF
HOT AT ALL TIMES
HTD/ SEATS FUSE
HVAC CONTROL MODULE (IN DASH CENTER TRIM PANEL, BENEATH RADIO)
I/P FUSE BLOCK
LOW REQ LOW REF
LT GRN WIRE
NCA WIRE
PASSENGER BACK HEATED SEAT ELEMENT (BEHIND UPHOLSTERY IN SEAT BACK)
PASSENGER CUSHION HEATED SEAT ELEMENT (IN PASSENGER'S SEAT ELEMENT)
PASSENGER HEATED SEAT HIGH INDICATOR
PASSENGER HEATED SEAT LOW INDICATOR
PASSENGER HEATED SEAT RELAY (UNDER PASSENGER SEAT)
PASSENGER HEATED SEAT SWITCH
PNK (OR WHT) WIRE
PNK (OR YEL) WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RED WIRE
RED/WHT WIRE
SPLICE PACK
TAN WIRE
TAN/WHT WIRE
W/ SIT-N-LIFT REAR SEAT
W/ SIT-N-LIFT REAR SEAT W/O SIT-N-LIFT REAR SEAT
W/O SIT-N-LIFT REAR SEAT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Heated seats circuit -> HIGH REQ LOW REQ LOW REF
