Chevrolet Uplander I (2004-2008) fusible link 242 (2 ga- Wiring diagram
This page shows the only wiring diagram for the component.fusible link 242 (2 ga-, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fusible link 242 (2 ga- (1 of 1)
12 VOLT REFERENCE
3.5L
A/C CLTCH RELAY
ABS MOTOR FUSE
AC CLTCH FUSE
BATT MAIN 1 FUSE
BATT MAIN 2 FUSE
BATT MAIN 3 FUSE
BATTERY STARTER MOTOR
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RESISTOR ASSEMBLY
BODY CONTROL MODULE (BCM) IGNITION 3 VOLTAGE
BRN WIRE
CRANK VOLTAGE
CRNK RELAY
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
FAN 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FAN-2 FUSE
FROM BATT MAIN 3 FUSE (DIAGRAM 1 OF 4)
FROM HORN FUSE (DIAGRAM 1 OF 4)
FRT BLWR HI FUSE
FRT WIPER FUSE
FRT WSW FUSE
FUEL PUMP FUSE
FUEL PUMP RELAY
FUSIBLE LINK 2 (8 GA-
FUSIBLE LINK 242 (2 GA-
GENERATOR
GRY/WHT WIRE
HI BEAM RELAY
HORN FUSE
HORN RELAY
I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL)
IGNITION 1 VOLTAGE
IGNITION SWITCH
LO BEAM RELAY
LOCK
PCM ETC FUSE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWR/TRN RELAY
RED WIRE
RR DEFOG FUSE
RR DEFOG RELAY 30
RUN RLY RELAY
RUN WIRE
STRTR SOL FUSE
TO 115 VAC AUXILIARY POWER OUTLET (DIAGRAM 2 OF 4)
TO FAN 1 FUSE (DIAGRAM 1 OF 4)
TO I/P FUSE BLOCK (DIAGRAM 3 OF 4)
TO I/P FUSE BLOCK (DIAGRAM 4 OF 4)
TOWARD RIGHT SIDE OF DASH)
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL)
W/ AUXILIARY POWER OUTLET
WHT WIRE
WPR 1 RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> FUSIBLE LINK 242 (2 GA-
