Chevrolet Uplander I (2004-2008) battery ind class 2 serial data Wiring diagram

3.9L 3.5L BATTERY BATTERY CURRENT SENSOR (RIGHT FRONT OF ENGINE COMT, NEAR BATTERY) BATTERY IND CLASS 2 SERIAL DATA BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) BRN WIRE CLASS 2 SERIAL DATA CLSTR/ HVAC FUSE 8 CURRENT SENS SIG CURRENT SENSE DK GRN WIRE FUSIBLE LINK (8 GA- GEN FIELD DUTY CYCLE SIGN GEN TURN ON SIG GENERATOR GROUND GRY WIRE HOT AT ALL TIMES I/P DIMMING VOLTAGE REF I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) IGN IGN 1 VOLT INSTRUMENT PANEL CLUSTER LOW REF LT GRN WIRE MODULE (ECM) (3.9L) (3.5L: LEFT SIDE OF ENGINE COMPT, IN AIR CLEANER ASSEMBLY) ORG/ WIRE ORG/WHT WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (3.5L) ENGINE CONTROL RED WIRE RED/WHT WIRE STARTER MOTOR WHT WIRE
