Chevrolet Uplander I (2004-2008) backup lmp sup volt Wiring diagram

This page shows the only wiring diagram for the component.backup lmp sup volt, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram backup lmp sup volt (1 of 1)

Wiring diagram backup lmp sup volt for Chevrolet Uplander I (2004-2008)

Get access

3.5L AUTOMATIC TRANSMISSION BACKUP LMP SUP VOLT BATT POSITIVE VOLT BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) CHMSL BACK-UP FUSE 17 (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) DK GRN/WHT WIRE GRN WIRE GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES I/P FUSE BLOCK INTERNAL MODE SWITCH (MS) LEFT BACK-UP LAMP LT GRN WIRE NAVIGATION SYSTEM (REAR PARKING ASSIST) RANGE SW B REAR OF VEHICLE) LT RED/BLK WIRE RED/WHT WIRE RIGHT BACK-UP LAMP SIG A SIG B TAN/WHT WIRE TRANS RANGE SW TRANSMISSION CONTROL MODULE (TCM) W/ REAR A/C YEL WIRE

Go to component: -> Backup lamps circuit -> BACKUP LMP SUP VOLT
