Chevrolet Uplander I (2004-2008) b+ class 2 ser data Wiring diagram

AMBIENT LIGHT SENSOR (IN CENTER OF DASH UPPER TRIM PANEL) B+ CLASS 2 SER DATA BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) BRN WIRE CLASS 2 SER DATA CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DRL AMB LT SENS SIG FLASH TO PASS SIGNAL FTP GRY WIRE HEAD HEADLAMP SWITCH HEADLAMPS OFF SIGNAL HEADLAMPS ON SIGNAL HI BEAM RELAY HIGH BEAM IND HIGH BEAM RELAY CONTROL HOT AT ALL TIMES LEFT FRONT PARK/TURN SIGNAL LAMP LEFT HIGH BEAM HEADLAMP LEFT LOW BEAM HEADLAMP LF TURN SIG LMP SPLY VOLT LH LO BEAM FUSE 8 LO BEAM RELAY LOGIC INSTRUMENT PANEL CLUSTER (IPC) LOW BEAM RELAY CONTROL LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MESSAGE CENTER HEADLAMPS SUGGESTED OFF AUTO PARK PNK WIRE PNK/WHT WIRE PPL PPL DIMMER SWITCH HI BM SIG RF TURN SIG LMP SPLY VOLT RH HI BEAM FUSE 1 RH LO BEAM FUSE 12 LH HI BEAM FUSE 4 RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT HIGH BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP TAN WIRE TAN/WHT WIRE TURN SIGNAL/ MULTIFUNCTION SWITCH WHT WIRE YEL WIRE
