Chevrolet Uplander I (2004-2008) 53 15 459 1049 33 15 rly ctrl class 2 data Wiring diagram

This page shows the only wiring diagram for the component.53 15 459 1049 33 15 rly ctrl class 2 data, which is found in the car Chevrolet Uplander I (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 53 15 459 1049 33 15 rly ctrl class 2 data (1 of 1)

Wiring diagram 53 15 459 1049 33 15 rly ctrl class 2 data for Chevrolet Uplander I (2004-2008)

Get access

3.9L 3.5L 53 15 459 1049 33 15 RLY CTRL CLASS 2 DATA 57 37 21 380 2700 2751 31 4 7 SENS SIG A/C CLTCH FUSE 6 A/C CLTCH RELAY A/C COMPRESSOR CLUTCH A/C REQUEST IND CNTRL A/C REQUEST IND A/C REQUEST SWITCH CLASS 2 DATA IGN BLK WIRE COMPUTER DATA LINES SYSTEM DIODE 3 DK GRN WIRE DK GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY ENERGIZED HVAC CONTROL MODULE (IN DASH CENTER TRIM PANEL, BENEATH RADIO) IGN A/C REQ LOGIC LOW REF ORG/BLK WIRE UNDERHOOD FUSE BLOCK (IN UNDERHOOD COMPT, ABOVE RIGHT FRONT WHEEL WELL) WHT WIRE

Go to component: -> Compressor circuit -> 53 15 459 1049 33 15 RLY CTRL CLASS 2 DATA
