Chevrolet Uplander I (2004-2008) 1 2 3 4 5 6 7 8 9 10 11 12 swivel mtr ctrl swivel mtr ctrl ground ground Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 SWIVEL MTR CTRL SWIVEL MTR CTRL GROUND GROUND BATTERY BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE CIRCUIT BREAKER ENCODER FUSE 1 FUSE 2 GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES I/P FUSE BLOCK (RIGHT SIDE OF DASH, BEHIND ACCESS PANEL) IGNITION SIGNAL RR DR OPEN SW SIG LIFT LOWER LIMIT SWITCH (IN SIT-N-LIFT SEAT BASE) LIFT MTR UP CTRL LIFT MTR DN CTRL BATTERY LIFT UPPER LIMIT SWITCH (IN SIT-N-LIFT SEAT BASE) NCA WIRE PARK SW SIG PPL PWR SEATS CIRCUIT BREAKER RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REMOTE UP SW SIG SIT-N- LIFT SEAT FUSE BLOCK SIT-N-LIFT SEAT CIRCUIT BREAKER SIT-N-LIFT SEAT LIFT MOTOR (IN SIT-N-LIFT SEAT BASE) SIT-N-LIFT SEAT MODULE (IN SIT-N-LIFT SEAT BASE) SPLICE SPLICE PACK SWIVEL INSIDE LIMIT SWITCH (IN SIT-N-LIFT SEAT BASE) SWIVEL MOTOR (IN SIT-N-LIFT SEAT BASE) SWIVEL OUTSIDE LIMIT SWITCH (IN SIT-N-LIFT SEAT BASE) SWVL MTR HALL SEN SIG SWVL MTR HALL SEN VLT WHT WIRE YEL WIRE YEL/BLK WIRE
