Courtesy lamps circuit for Chevrolet Trax II (2023-2024)

BATT POS VOLT BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (UNDER CENTER OF DASH) COMPUTER DATA LINES SYSTEM COURTESY LAMP SWITCH SIGNAL GRN/GRY WIRE GROUND GRY WIRE GRY/GRN WIRE HI SPD GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES INADVERTENT LOAD CTRL INSTRUMENT PANEL FUSE BLOCK INTERIOR LAMP CTRL INTERIOR LAMP DEFEAT SWITCH SIGNAL LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR WINDOW SWITCH LIFTGATE AJAR SWITCH SIGNAL 1 LIFTGATE LATCH LOGIC REAR COMPARTMENT COURTESY LAMP REAR COMPARTMENT COURTESY LAMP CTRL REAR DOME READING LAMPS RED/WHT WIRE VIO/GRY WIRE WHT WIRE WHT/BRN WIRE

BLK WIRE BLK/WHT WIRE BLU/VIO WIRE COMPUTER DATA LINES SYSTEM DOME LAMP IND DOME LAMP OFF SWITCH DOME/READING LAMPS DRIVER DOOR LATCH ASSEMBLY DRIVER WINDOW MOTOR DRIVER WINDOW SWITCH GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/GRN WIRE GRY/YEL WIRE LOGIC PASSENGER DOOR LATCH ASSEMBLY PASSENGER WINDOW SWITCH RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR WINDOW SWITCH W/ EXPRESS UP/DOWN W/O EXPRESS UP/DOWN WHT/VIO WIRE
