Chevrolet Trax II (2023-2024) underhood fuse block rear defogger relay Wiring diagram
This page shows the only wiring diagram for the component.underhood fuse block rear defogger relay, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram underhood fuse block rear defogger relay (1 of 1)
BATTERY
BATTERY SENSOR MODULE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
HIGH NOTE HORN
IGNITION MAIN RELAY
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT PARK LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP LED DRIVER MODULE
LEFT HEADLAMP LEVELING ACTUATOR
NCA WIRE
REAR DEFOGGER RELAY
REAR WINDOW WASHER PUMP RELAY
REAR WIPER RELAY
RIGHT DAYTIME RUNNING LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP LED DRIVER MODULE
RIGHT HEADLAMP LEVELING ACTUATOR
UNDERHOOD FUSE BLOCK REAR DEFOGGER RELAY
W/ MANUAL HEADLAMPS LEVELING SYSTEM
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
Go to component -> Ground distribution circuit (1 of 5) -> UNDERHOOD FUSE BLOCK REAR DEFOGGER RELAY
