Chevrolet Trax II (2023-2024) trans park/ neutral sig 1 Wiring diagram
This page shows the only wiring diagram for the component.trans park/ neutral sig 1, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans park/ neutral sig 1 (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BACKUP LP CTRL
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (UNDER CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FEEDBACK SIG
GRN/WHT WIRE
GRY/BRN WIRE
GRY/WHT WIRE
HI SPD GMLAN SER DATA (+) 1
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
INSIDE REAR VIEW MIRROR
INSTRUMENT PANEL FUSE BLOCK
LEFT BACKUP LAMP
LEFT TAIL LAMP ASSEMBLY
LOGIC
NCA WIRE
P/N SIG
P/N SIG 1
RADIO
RED/VIO WIRE
RIGHT BACKUP LAMP
RIGHT TAIL LAMP ASSEMBLY
SIG A
SIG B
SIG C
SIG P
TRANS PARK/ NEUTRAL SIG 1
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SENSOR
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRY WIRE
Go to component -> Backup lamps circuit -> TRANS PARK/ NEUTRAL SIG 1
