Chevrolet Trax II (2023-2024) snow mode switch Wiring diagram
This page shows the only wiring diagram for the component.snow mode switch, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram snow mode switch (1 of 1)
AUTO IND
AUTO SWITCH
BATTERY FUSE BLOCK
BATTERY POS VOLTAGE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLOWER MOTOR
BLOWER MOTOR CONTROL MODULE
BLOWER MTR CTRL
BLOWER MTR SPD CTRL
BLU/GRY WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFROST, LOWER AIR OUTLET IND
DEFROST, LOWER AIR OUTLET SWITCH
FAN DOWN SWITCH
FAN UP SWITCH
FRONT BLOWER
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HVAC CONTROLS
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
MTR CTRL
ON/OFF IND
ON/OFF SWITCH
REAR WINDOW DEFROST SWITCH
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
SNOW MODE IND
SNOW MODE SWITCH
TEMPERATURE CONTROL
TEMPERATURE DOWN SWITCH
TEMPERATURE UP SWITCH
UNDERHOOD FUSE BLOCK
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
UPPER, LOWER AIR OUTLET IND
UPPER, LOWER AIR OUTLET SWITCH
VIO WIRE
VIO/BLK WIRE
WINDSHIELD DEFROST IND
WINDSHIELD DEFROST SWITCH
Go to component -> Automatic a/c circuit (2 of 5) -> SNOW MODE SWITCH
