Chevrolet Trax II (2023-2024) rear middle parking assist sensor Wiring diagram
This page shows the only wiring diagram for the component.rear middle parking assist sensor, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear middle parking assist sensor (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/GRY WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LEFT REAR OUTER PARKING ASSIST SENSOR
LOW SPEED GMLAN SERIAL DATA
LR OUTER PARKING ASSIST SENS SIG
OBJECT SENS LOW REF
OBJECT SENS VOLT REF
PARKING ASSIST CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT)
REAR MIDDLE PARKING ASSIST SENSOR
RED/GRN WIRE
RIGHT REAR OUTER PARKING ASSIST SENSOR
RR MIDDLE PARKING ASSIST SENS SIG
RR OUTER PARKING ASSIST SENS SIG
YEL WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit -> REAR MIDDLE PARKING ASSIST SENSOR
