Chevrolet Trax II (2023-2024) pos act sol vlv 1 Wiring diagram
This page shows the only wiring diagram for the component.pos act sol vlv 1, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pos act sol vlv 1 (1 of 1)
AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAM POS ACT SOL VLV 1
CAM POS SENS 1
CHARGE INDICATOR CTRL
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
EVAPORATIVE EMISSION VENT SOLENOID VALVE
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGNITION CTRL 2
INTAKE CAM POS SENS 1
KNOCK SENSOR
POS ACT SOL VLV 1
POS SENS SIG
POWER SUPPLY TRANSFORMER
RED/BLU WIRE
RED/WHT WIRE
REPLICATED SIG
SEN BUS ENABLE
SENS 1 VOLT REF
SOUND SYSTEMS
STARTING/ CHARGING SYSTEMS
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VLV LOW SIDE CTRL
W/ FRONT GRILLE SHUTTERS
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 1.2l vin 2 (5 of 7) -> POS ACT SOL VLV 1
