Chevrolet Trax II (2023-2024) pass seat back heating temp sig Wiring diagram
This page shows the only wiring diagram for the component.pass seat back heating temp sig, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat back heating temp sig (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BODY CTRL MODULE LIN BUS 2
BRN/BLK WIRE
BRN/BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACK SEAT HEATING ELEMENT
DRIVER CUSHION SEAT HEATING ELEMENT
DRV SEAT BACK HEATING TEMP SIG
DRV SEAT BLOWER MOTOR CTRL 1
DRV SEAT HEATING ELEMENT CTRL
DRV SEAT HEATING ELEMENT LO REF
DRV SEAT HEATING TEMP SIG
DRV SEAT HEATING THERMISTOR LO REF
GRN/BLU WIRE
GRN/VIO WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
NCA WIRE
PASS HEATED BACK THERMISTOR LO REF
PASS SEAT BACK HEATING TEMP SIG
PASS SEAT BLOWER MOTOR CTRL 1
PASS SEAT HEATING ELEMENT CTRL
PASS SEAT HEATING ELEMENT LO REF
PASS SEAT HEATING TEMP SIG
PASS SEAT HEATING THERMISTOR LO REF
PASSENGER BACK SEAT HEATING ELEMENT
PASSENGER CUSHION SEAT HEATING ELEMENT
RED/BLU WIRE
RED/GRN WIRE
SEAT HEATING CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT)
UNDERHOOD FUSE BLOCK
VIO/WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/GRY WIRE
Go to component -> Heated seats circuit (1 of 2) -> PASS SEAT BACK HEATING TEMP SIG
