Chevrolet Trax II (2023-2024) lid motor unlatch control Wiring diagram
This page shows the only wiring diagram for the component.lid motor unlatch control, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lid motor unlatch control (1 of 1)
BATT POS VOLT
BLK WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
ENDGATE LATCH RELAY COIL CONTROL
GRN WIRE
GROUND
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LID MOTOR UNLATCH CONTROL
LIFTGATE AJAR SWITCH SIGNAL 1
LIFTGATE LATCH
LIFTGATE UNLATCH RELAY
LOGIC
LOW SPEED GMLAN SERIAL DATA
LOW SPEED GMLAN SERIAL DATA 2
MULTI-FUNCTION CARRIER LICENSE PLATE LAMP
REAR CLOSURE HANDLE SWITCH OPEN SIGNAL
RED/BRN WIRE
UNDERHOOD FUSE BLOCK
VIO/GRY WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Liftgate release circuit -> LID MOTOR UNLATCH CONTROL
