Chevrolet Trax II (2023-2024) hvac ctrl mod lin bus 2 Wiring diagram

ACC IGN VOLT ACC WAKE-UP SER DATA BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/YEL WIRE BODY CONTROL MODULE (UNDER CENTER OF DASH) BODY CTRL MOD BODY CTRL MOD LIN BUS 1 BODY CTRL MOD LIN BUS 2 BODY CTRL MOD LIN BUS 3 BODY CTRL MOD LIN BUS 4 DATA LINK CONNECTOR (LEFT SIDE OF DASH) GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (-) 2 HOT AT ALL TIMES HVAC CONTROL MODULE (UNDER CENTER OF DASH) HVAC CONTROLS HVAC CTRL MOD LIN BUS 1 HVAC CTRL MOD LIN BUS 2 IMMOBILIZER CONTROL MODULE IMMOBILIZER LIN BUS 1 INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE INSTRUMENT PANEL FUSE BLOCK KEYLESS ENTRY CONTROL MODULE (IF EQUIPPED) (BEHIND LEFT CENTER OF DASH) LEFT REAR WINDOW SWITCH LIFTGATE CONTROL MODULE (IF EQUIPPED) (NEAR TOP OF LEFT "D" PILLAR) LIN BUS 2 LO SPD GMLAN LO SPD GMLAN SER DATA LO SPD GMLAN SERIAL DATA LOGIC PARKING ASSIST CONTROL MODULE (IF EQUIPPED) (RIGHT SIDE OF LUGGAGE COMPT) PASSENGER PRESENCE MODULE RED/BRN WIRE RIGHT REAR WINDOW SWITCH SEAT HEATING CONTROL MODULE SER DATA COMM ENABLE SERIAL DATA SERIAL DATA COMM ENABLE SUNROOF CONTROL MODULE (IF EQUIPPED) (REAR LEFT SIDE OF SUNROOF ASSEMBLY) TRANSMISSION SHIFT LEVER POSITION INDICATOR VIO/YEL WIRE W/ SEAT HEATER W/ START KEYLESS SWITCH WHT WIRE WHT/BLU WIRE
