Chevrolet Trax II (2023-2024) driver exterior door handle assembly Wiring diagram
This page shows the only wiring diagram for the component.driver exterior door handle assembly, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver exterior door handle assembly (1 of 1)
2 WAY
8 WAY
BLK WIRE
BODY CONTROL MODULE
DOME/ READING LAMPS
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR LOCK SWITCH
DRIVER EXTERIOR DOOR HANDLE ASSEMBLY
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
INSIDE REAR VIEW MIRROR
INTERIOR LIFTGATE CONTROL SWITCH
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW SWITCH
NCA WIRE
PASSENGER AIR BAG DISABLED INDICATOR
POWER SUPPLY TRANSFORMER
REAR DOME READING LAMPS
SUNROOF SWITCH
SUNROOF TILT SWITCH
TELEMATICS BUTTON ASSEMBLY
TRANSMISSION SHIFT LEVER
W/ EXPRESS UP/DOWN
W/ INFLATABLE RESTRAINT SENSOR INDICATOR
W/ POWER LIFTGATE
W/ VEHICLE COMMUNICATION SYSTEM
WHT WIRE
WINDSHIELD FRONT VIEW CAMERA
WINDSHIELD TEMPERATURE, INSIDE MOISTURE SENSOR
Go to component -> Ground distribution circuit (5 of 5) -> DRIVER EXTERIOR DOOR HANDLE ASSEMBLY
