Chevrolet Trax II (2023-2024) automatic transmission assembly control solenoid valve assembly Wiring diagram
This page shows the only wiring diagram for the component.automatic transmission assembly control solenoid valve assembly, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic transmission assembly control solenoid valve assembly (1 of 1)
A/C COMPRESSOR CLUTCH
ACTIVE GRILLE AIR SHUTTER ACTUATOR 1
AUTOMATIC A/C
AUTOMATIC TRANSMISSION ASSEMBLY CONTROL SOLENOID VALVE ASSEMBLY
AUXILIARY COOLANT PUMP
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BRAKE SYSTEM CONTROL MODULE
COOLING FAN MOTOR
ENGINE CONTROL MODULE
EVAPORATIVE EMISSION PURGE PUMP
HVAC CONTROL MODULE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
LIFTGATE CONTROL MODULE
LIFTGATE LATCH
MANUAL A/C
MOBILE DEVICE WIRELESS CHARGER MODULE
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
RADIO
RADIO CONTROLS
REAR DEFOGGER GRID
REAR WIPER MOTOR
SUNROOF CONTROL MODULE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
UNDERHOOD FUSE BLOCK STARTER RELAY
USB RECEPTACLE
W/ INFLATABLE RESTRAINT
W/ MANUAL LIFTGATE
W/ STOP/START SYSTEM
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> AUTOMATIC TRANSMISSION ASSEMBLY CONTROL SOLENOID VALVE ASSEMBLY
