Chevrolet Trax II (2023-2024) automatic hi beam on/off sw sig Wiring diagram
This page shows the only wiring diagram for the component.automatic hi beam on/off sw sig, which is found in the car Chevrolet Trax II (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic hi beam on/off sw sig (1 of 1)
AMBIENT LIGHT SENS SIG
AMBIENT LIGHT/ SUNLOAD SENSOR
AUTOMATIC HI BEAM ON/OFF SW SIG
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (UNDER CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
FTP
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HDLP HI BEAM CTRL
HDLP SW FLASH SIG HI BEAM SELECT SW HI BEAM SIG
HDLP SW OFF SIG
HDLP SW ON SIG
HIGH BEAM ASSIST SWITCH
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
HVAC CONTROL MODULE
INSTRUMENT PANEL FUSE BLOCK
LEFT DAYTIME RUNNING LAMP CONTROL MODULE
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT DRL CTRL
LEFT FRONT PARK LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP LED DRIVER MODULE
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT PARK LAMP CTRL
LH HDLP LOW BEAM CTRL
NCA WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RH HDLP LOW BEAM CTRL
RIGHT FRONT DRL CTRL
RIGHT PARK LAMP CTRL
SS LOW REF
TURN SIGNAL/ MULTI-FUNCTION SWITCH
VIO/GRY WIRE
W/ LED
W/O LED
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 2) -> AUTOMATIC HI BEAM ON/OFF SW SIG
