Chevrolet Trax II (2023-2024) air temp door ctrl 3 Wiring diagram

A/C COMPRESSOR CLUTCH RLY CTRL A/C EVAPORATOR TEMP SENS SIG A/C REFRIGERANT PRESS SENS SIG AIR INLET DOOR ACTUATOR AIR INLET DOOR ACTUATOR CTRL 1 AIR INLET DOOR ACTUATOR CTRL 2 AIR INLET DOOR ACTUATOR CTRL 3 AIR INLET DOOR ACTUATOR CTRL 4 AIR TEMP DOOR CTRL 1 AIR TEMP DOOR CTRL 2 AIR TEMP DOOR CTRL 3 AIR TEMP DOOR CTRL 4 AIR TEMPERATURE DOOR ACTUATOR AMBIENT AIR TEMPERATURE SENS SIG BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FAN HIGH SPEED RLY CTRL COOLING FAN LOW SPEED RLY CTRL ENG COOLANT TEMP SENS SIG ENGINE CONTROL MODULE ENGINE CTRL MODULE LIN BUS 1 ENGINE CTRL SENS 5 VOLT REF 1 ENGINE CTRL SENS LOW REF 2 FAN 3 CTRL GRN WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE HI SPD GMLAN SERIAL DATA (-) (1) HVAC CONTROL MODULE (UNDER CENTER OF DASH) HVAC DOOR ACTUATOR CTRL LOGIC LOW REF (1) MODE DOOR ACTUATOR MODE DOOR CTRL 1 MODE DOOR CTRL 2 MODE DOOR CTRL 3 MODE DOOR CTRL 4 SENSOR LOW REFR SNOW IND SNOW SWITCH VIO/GRN WIRE WHT WIRE WHT/BLK WIRE WHT/GRY WIRE YEL WIRE YEL/GRN WIRE
