Chevrolet Trax I facelift (2016-2022) right corner sens Wiring diagram
This page shows the only wiring diagram for the component.right corner sens, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right corner sens (1 of 1)
AID DISPLAY CTRL
BATT POSITIVE VOLT
BCM 5 FUSE
BCM 6 FUSE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DISABLE SIG
GRN WIRE
GRN/BRN WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LED DISABLE SIG
LEFT CORNER SENS
LEFT FRONT MIDDLE PARKING ASSIST SENSOR
LEFT FRONT OUTER PARKING ASSIST SENSOR
LEFT MID SENS
LOW SPD GMLAN SERIAL DATA
LR CORNER OBJECT SENS SIG
LR MIDDLE OBJECT SENS SIG
OBJECT SENS CTRL
OBJECT SENS LOW REF
PARKING ASSIST CONTROL MODULE
PAS SMZA FUSE
POWER DISTRIBUTION SYSTEM
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CORNER SENS
RIGHT FRONT MIDDLE PARKING ASSIST SENSOR
RIGHT FRONT OUTER PARKING ASSIST SENSOR
RIGHT MID SENS
RR CORNER OBJECT SENS SIG
RR MIDDLE OBJECT SENS SIG
SENS LOW REF
SIG GND
VIO/GRY WIRE
VIO/WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit (1 of 2) -> RIGHT CORNER SENS
