Chevrolet Trax I facelift (2016-2022) rdcm fuse Wiring diagrams
This page contains all the electrical diagrams for the component. rdcm fuse, in which he is found in the car Chevrolet Trax I facelift (2016-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rdcm fuse (1 of 2)
ACC LED SIG
AMPLIFIER FUSE
AUDIO AMPLIFIER
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
COIL CTRL
DC/DC IN FUSE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 6)
GRN WIRE
GRY WIRE
IGN MODE SW
KEYLESS ENTRY CONTROL MODULE
MODE VOLT
PASSIVE START
RAP RLY 2
RDCM FUSE
REAR BODY FUSE BLOCK (LEFT SIDE OF LUGGAGE COMPT)
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
RED WIRE
START LED SIG
SW 2 LOW REF
SW SIG 2
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 6 OF 6)
TO POWER INVERTER MODULE (DIAGRAM 3 OF 6)
TO POWER SUPPLY TRANSFORMER DIAGRAM (6 OF 6)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> RDCM FUSE
Wiring diagram rdcm fuse (2 of 2)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
GMLAN SERIAL DATA (+) (1) GMLAN SERIAL DATA (+) (2)
GMLAN SERIAL DATA - 1
GMLAN SERIAL DATA 2
HIGH CTRL
HOT AT ALL TIMES
LOW CTRL
RDCM FUSE
REAR BODY FUSE BLOCK
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR DIFFERENTIAL CLUTCH SOLENOID VALVE
RED WIRE
RED/BRN WIRE
SERIAL DATA COMM
WHT WIRE
WHT/BLU WIRE
Go to component -> Rear differential lock circuit -> RDCM FUSE
