Chevrolet Trax I facelift (2016-2022) ptc_1 lpm fuse Wiring diagram
This page shows the only wiring diagram for the component.ptc_1 lpm fuse, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ptc_1 lpm fuse (1 of 1)
AMBIENT AIR TEMPERATURE SENSOR
BATT POS VOLT
BLK WIRE
BLK/LT BLU WIRE
BLOWER MOTOR RELAY
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTOR
COOLING FAN RELAY
COOLING FAN RESISTOR (LOWER LEFT SIDE OF DASH)
COOLING FAN SPEED CONTROL RELAY
DRIVER INFORMATION CENTER DISPLAY
GRN WIRE
GRN/VIO WIRE
GRY WIRE
GRY/GRN WIRE
HIGH SPEED GMLAN
HOT AT ALL TIMES
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
HVAC MDL FUSE
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IPC B+ FUSE
LOGIC
LOW SPEED GMLAN SERIAL DATA 2
LT BLU/GRY WIRE
OUTSIDE AMBIENT AIR TEMP SENS SIG
OUTSIDE AMBIENT TEMP SENS LOW REF
PTC_1 LPM FUSE
PTC_2 FUSE
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RUN RELAY COIL CTRL
SERIAL DATA (-) (1)
UNDERHOOD RELAY BLOCK
VIO/BLU WIRE
VIO/BRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 3) -> PTC_1 LPM FUSE
