Chevrolet Trax I facelift (2016-2022) mid level low level w/ bypass module w/o bypass module Wiring diagram
This page shows the only wiring diagram for the component.mid level low level w/ bypass module w/o bypass module, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mid level low level w/ bypass module w/o bypass module (1 of 1)
BACKUP LAMP CTRL
BACKUP LP CTRL
BATT +
BCM 6 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CAMERA SHIELD GND EXTENSION CAMERA SIG 2 +
CAMERA SIG 2
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GMLAN SERL DATA (+) 1
GRN/WHT WIRE
GROUND
GRY WIRE
GRY/LT GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
ISRVM REAR VIEW CAM FUSE
LOGIC
LT BLU WIRE
MID LEVEL LOW LEVEL W/ BYPASS MODULE W/O BYPASS MODULE
NCA WIRE
RADIO
RAP RELAY COIL CONTROL
REAR VIEW CAMERA
RED/VIO WIRE
RUN/CRANK IGN 1 VOLT
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Rear view camera circuit (1 of 2) -> MID LEVEL LOW LEVEL W/ BYPASS MODULE W/O BYPASS MODULE
