Chevrolet Trax I facelift (2016-2022) ibs fuse Wiring diagram

1.4L VIN M TURBO 1.4L VIN B TURBO AOS FUSE AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE BATTERY BATTERY FUSE BLOCK BATTERY SENSOR MODULE BLU WIRE BRAKE BOOSTER PUMP MOTOR RELAY UNDERHOOD RELAY BLOCK BRN WIRE CANISTER VENT SOLENOID FUSE CHASSIS CONTROL MODULE CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY DRIVER SEAT LUMBAR SUPPORT SWITCH DRIVER WINDOW SWITCH EBCM PUMP FUSE EBCM PWR FUSE ECM PT IGN-3 FUSE ECM-B FUSE ELECTRONIC BRAKE CONTROL MODULE ENGINE CONTROL MODULE ENGINE CONTROLS IGNITION RELAY ENGINE COOLANT THERMOSTAT HEATER ENGINE OIL PRESSURE CONTROL SOLENOID VALVE EVAPORATIVE EMISSION PURGE SOLENOID VALVE EVAPORATIVE EMISSION VENT SOLENOID VALVE EVP FUSE FRT WIPER FUSE FSCM B+ FUSE FUSE 1 FUSE 2 FUSE 25 FUSE 4 FUSE 5 GARAGE DOOR OPENER GENERATOR GRN WIRE GRY WIRE HEATED OXYGEN SENSOR 1 HEATED OXYGEN SENSOR 2 HEATED SEAT MODULE FUSE IBS FUSE LT GRN WIRE MULTI-FUNCTION INTAKE AIR SENSOR MULTI-FUNCTION WINDSHIELD SENSOR NCA WIRE OUTSIDE REAR VIEW MIRROR SWITCH PASSENGER PRESENCE MODULE PASSENGER SEAT LUMBAR SUPPORT SWITCH POWER STEERING CONTROL MODULE PWR LUMBAR SW FUSE RAIN SENSOR, OSRVM SW, DRIVER WINDOW SW, UGDO FUSE RAIN/AMBIENT LIGHT SENSOR MODULE RED WIRE RED/GRN WIRE SEAT HEATING CONTROL MODULE SEAT MEMORY CONTROL MODULE STARTER MOTOR SUNROOF CONTROL MODULE SUNROOF FUSE TCM B FUSE TO COOL FAN HIGH FUSE (DIAGRAM 2 OF 6) TO FUSE 3 (DIAGRAM 4 OF 6) TO IGNITION COIL/ INJECTOR COIL FUSE (DIAGRAM 2 OF 6) TO REAR BODY FUSE BLOCK (DIAGRAM 5 OF 6) TRANSMISSION CONTROL MODULE TURBOCHARGER BYPASS SOLENOID VALVE TURBOCHARGER WASTEGATE SOLENOID VALVE UNDERHOOD FUSE BLOCK VIO WIRE W/ MEMORY W/O LANE DEPARTURE WARNING ACTIVE SAFETY W/O MEMORY W/O MEMORY W/ MEMORY WHT WIRE WINDSHIELD WIPER RELAY WINDSHIELD WIPER SPEED CONTROL RELAY YEL WIRE
