Chevrolet Trax I facelift (2016-2022) human machine interface control module bypass module Wiring diagram
This page shows the only wiring diagram for the component.human machine interface control module bypass module, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram human machine interface control module bypass module (1 of 1)
AUXILIARY AUDIO INPUT
BASE
BATT POS VOL
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BLOWER MOTOR RELAY
BLU WIRE
BLU/BRN WIRE
BUICK CHEVROLET 1.4L (VIN M) TURBO MID LEVEL LOW LEVEL
DC TO AC INVERTER CTRL GND
FP (INFOTAINMENT) FUSE
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 6 OF 6)
FROM POWER SUPPLY TRANSFORMER DIAGRAM (6 OF 6)
FROM REAR BODY FUSE BLOCK (DIAGRAM 5 OF 6)
FROM REAR DEFOGGER RELAY (DIAGRAM 2 OF 6)
GRN WIRE
GRY WIRE
HUMAN MACHINE INTERFACE CONTROL MODULE
HUMAN MACHINE INTERFACE CONTROL MODULE BYPASS MODULE
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
IPC B+ FUSE
LPM FUSE
ONS GLONAS FUSE
POWER INVERTER MODULE
RADIO
REAR WINDOW WASHER PUMP RELAY
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
SIL BOX AUDIO NAV FUSE
STARTER FUSE
STARTER PINION SOLENOID ACTUATOR RELAY
STARTER RELAY
STARTER SOL FUSE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
UNDERHOOD FUSE BLOCK
VIO WIRE
W/ ONSTAR
WASHER PUMP FUSE
WHT WIRE
WINDSHIELD WASHER PUMP RELAY
Go to component -> Power distribution circuit (3 of 6) -> HUMAN MACHINE INTERFACE CONTROL MODULE BYPASS MODULE
