Chevrolet Trax I facelift (2016-2022) batt pos volt lane departure warning ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.batt pos volt lane departure warning ind ctrl, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt pos volt lane departure warning ind ctrl (1 of 1)
BATT +
BATT POS VOLT LANE DEPARTURE WARNING IND CTRL
BATT POSITIVE VOLT
BCM 5 FUSE
BCM 6 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
FRONT VIEW CAMERA WINDSHIELD
GRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
IND DIMMING CTRL
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LANE DEPARTURE WARNING DISABLE
LANE DEPARTURE WARNING DISABLE SWITCH
LANE DEPARTURE WARNING IND
LANE DEPARTURE WARNING SWITCH
LDW ISRVM FUSE
LED BACKLIGHT DIMMING CTRL
LEFT STEERING WHEEL CONTROLS SWITCH
LO SPD GMLAN SERIAL DATA
LOGIC
LOW SPD GMLAN SER DATA
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
STEERING WHEEL AIR BAG COIL
SW SIG
WHT WIRE
YEL WIRE
Go to component -> Lane departure warning circuit, w/o forward collision alert -> BATT POS VOLT LANE DEPARTURE WARNING IND CTRL
