Chevrolet Trax I facelift (2016-2022) amplifier ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. amplifier ctrl, in which he is found in the car Chevrolet Trax I facelift (2016-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram amplifier ctrl (1 of 2)
AM/FM
AMPLIFIER CTRL
AUDIO AMPLIFIER (RIGHT SIDE OF LUGGAGE COMPT)
AUXILIARY AUDIO INPUT
BACKUP LAMP CTRL
BATT POS VOLT
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAMERA SIG 2
CELL
CELLULAR PHONE ANTENNA
COAX
COAX BK
COAX BU
COAX GD
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
ETHERNET BUS 7 (-)
FRT LO LEVEL AUDIO (-)
GMLAN SERIAL DATA 2
GPS
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/LT GRN WIRE
GRY/YEL WIRE
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LF LO LEVEL AUDIO SIG
LF LO LEVEL AUDIO-
LF SPEAKER (-) CTRL 1
LF SPEAKER SIG (-) 1
LR LO LEVEL AUDIO (-)
LR LO LEVEL AUDIO SIG
LR SPEAKER (+) CTRL
LR SPEAKER SIG (-)
NAVIGATION ANTENNA
NAVIGATION SYSTEM
NCA WIRE
RADIO
RADIO ANTENNA
REAR VIEW CAMERA CIRCUIT
RED/GRY WIRE
REMOTE ENABLE SIG
RF LO LEVEL AUDIO SIG
RF SPEAKER (-) CTRL 1
RF SPEAKER SIG (-) 1
ROOF REAR ANTENNA
RR LO LEVEL AUDIO SIG
RR LO LEVEL AUDIO-
RR SPEAKER (+) CTRL
RR SPEAKER SIG (-)
SIG GND
SILBOX- AUDIO-NAV FUSE
TBD GND
USB
USB BK USB SERIAL DATA
USB SERIAL DATA
VIO/BLU WIRE
VOICE REC AUDIO LO REF
VOICE REC AUDIO SIG
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Navigation circuit, low level w/ amplifier (1 of 3) -> AMPLIFIER CTRL
