Chevrolet Trax I facelift (2016-2022) ac pwr prndl fuse wiring diagram
This page shows the only wiring diagram for the component.ac pwr prndl fuse, which is found in the car Chevrolet Trax I facelift (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ac pwr prndl fuse wiring diagram (1 of 1)
1.4L (VIN B) TURBO 1.4L (VIN M) TURBO
AC PWR PRNDL FUSE
ACC WAKEUP
ACCESSORY VOLTAGE
ACCESSORY WAKEUP SERIAL DATA
APO DC FRT FUSE
BATTERY
BATTERY SAVER RELAY 1
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
CIGARETTE LIGHTER RECEPTACLE
COMPUTER DATA LINES SYSTEM
DATA (-) (3)
ENABLE
ENGINE CONTROL MODULE
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 6)
FROM KEYLESS ENTRY CONTROL MODULE (DIAGRAM 5 OF 6)
FROM LDW ISRVM FUSE (DIAGRAM 4 OF 6)
FROM REAR BODY FUSE BLOCK (DIAGRAM 5 OF 6)
GRN WIRE
GROUND
GRY WIRE
IGN 1 VOLT
IGNITION KEY RESISTOR SIG
IGNITION SWITCH
KEY-IN IGNITION SWITCH
LOG MODE RLY COIL CTRL
LOG MODE RLY OPEN CTRL
LOGISTIC MODE RLY DC/DC FUSE
OFF
OFF/RUN/CRANK VOLTAGE
POSITIVE
POWER SUPPLY TRANSFORMER
RAP RLY COIL CTRL
RED WIRE
RETAINED ACCESSORY POWER RELAY
RLY CTRL
RUN WIRE
RUN/CRANK
RUN/CRANK IGNITION 1 VOLTAGE
RUN/CRANK RELAY COIL CTRL
SERIAL
SERIAL DATA
SPLY
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 6)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 2 OF 6)
TO UNDERHOOD FUSE BLOCK (DIAGRAM 3 OF 6)
UNDERHOOD FUSE BLOCK
VIO WIRE
VOLT
VOLT 1
VOLT 2
W/ KEYLESS ENTRY
W/ STOP/ START SYSTEM
W/O KEYLESS ENGINE START SWITCH
W/O KEYLESS ENTRY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> AC PWR PRNDL FUSE
