Chevrolet Trax I (2013-2017) osrvm heat fuse wiring diagram
This page shows the only wiring diagram for the component.osrvm heat fuse, which is found in the car Chevrolet Trax I (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
osrvm heat fuse wiring diagram (1 of 1)
BATTERY FUSE BLOCK
BLK WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER OUTSIDE REAR- VIEW MIRROR
FUSE 4
GRN WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE
LOGIC
OSRVM HEAT FUSE
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR DEFOG
REAR DEFOGGER GRID
REAR DEFOGGER IND
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
RED/GRN WIRE
RR WDW DEFOG FUSE
SERIAL DATA
UNDERHOOD FUSE BLOCK
Go to component -> Defoggers circuit -> OSRVM HEAT FUSE
