Chevrolet Trax I (2013-2017) hi spd gmlan serial data+ ambient light snsr sig wiring diagram
This page shows the only wiring diagram for the component.hi spd gmlan serial data+ ambient light snsr sig, which is found in the car Chevrolet Trax I (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
hi spd gmlan serial data+ ambient light snsr sig wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP RLY CTRL
FRONT FOG LAMP FUSE
FRONT FOG LAMP RELAY
FTP
GRN/BRN WIRE
HDLP DIMMER SW HI BEAM SIG
HDLP HI BEAM RLY CTRL
HDLP SW FLASH TO PASS SIG
HDLP SW HDLP OFF SIG CTRL
HDLP SW ON SIG
HEADLAMP HIGH BEAM RELAY
HI SPD GMLAN SERIAL DATA
HI SPD GMLAN SERIAL DATA+ AMBIENT LIGHT SNSR SIG
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LH HDLP LW BEAM SPLY VOLT
LH HIGH BEAM FUSE
LIGHTING CTRL SW REF
LIGHTING CTRL SW SIG
NCA WIRE
PARK BRAKE SWITCH
PARK BRK SW SIG
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RH HDLP LW BEAM SPLY VOLT
RH HIGH BEAM FUSE
RIGHT HEADLAMP ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SIG GROUND
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Headlights circuit (1 of 2) -> HI SPD GMLAN SERIAL DATA+ AMBIENT LIGHT SNSR SIG
