Chevrolet Trax I (2013-2017) evp sw fuse Wiring diagram
This page shows the only wiring diagram for the component.evp sw fuse, which is found in the car Chevrolet Trax I (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evp sw fuse (1 of 1)
AC/DC INV FUSE
AMPLIFIER FUSE
AOS MDL FUSE
AUDIO AMPLIFIER
AWD MDL FUSE
BATT FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
EVP SW FUSE
EWP SW FUSE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 6)
GRN WIRE
GRY WIRE
HTD STR WHL FUSE
HVAC CONTROL MODULE
IGNITION MAIN RELAY
IGNITION RUN RELAY
INSIDE REAR VIEW MIRROR
ISRVM/ RVC FUSE
LEFT SIDE OBJECT SENSOR MODULE
NAV DOCK FUSE
PASSENGER PRESENCE SENSOR
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
PWR LUM SW DR FUSE
PWR LUM SW PASS FUSE
PWR SEAT SW DR/MEMORY MDL FUSE
PWR SEAT SW PASS FUSE
REAR BODY FUSE BLOCK
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR VIEW CAMERA (IF EQUIPPED)
RED WIRE
RIGHT SIDE OBJECT SENSOR MODULE
SEAT MEMORY CONTROL MODULE
SPARE FUSE
SPARE/ LPG MDL B+ FUSE
SPARE/ SBZA B+ FUSE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATING CONTROL MODULE
TO POWER INVERTER MODULE (DIAGRAM 3 OF 6)
TRLR MDL FUSE
TRLR PARK LP FUSE
TRLR SOCKET FUSE
VIO WIRE
VIO/GRY WIRE
W/ CHILD PRESENCE DETECTOR
W/ MEMORY W/O MEMORY
WATER IN FUEL SENSOR FUSE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> EVP SW FUSE
