Car Wiring Diagrams for Rear heated seats circuit for Chevrolet Traverse II (2017-2021)

AUXILIARY HVAC CONTROLS BATT POS VOLT BLK WIRE BLU/BLK WIRE BLU/BRN WIRE COMPUTER DATA LINES SYSTEM GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/YEL WIRE GRY WIRE HIGH HEAT IND HOT AT ALL TIMES LEFT REAR CUSHION SEAT HEATING ELEMENT LEFT REAR HEATED, BACK SWITCH LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 2 LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 9 LOGIC LOW HEAT IND LOW HEAT IND MED HEAT IND LR HTD SEAT ELEMENT CTRL LR HTD SEAT ELEMENT LO REF LR HTD SEAT NTC LO REF LR HTD SEAT NTC SIG MED HEAT IND NCA WIRE PPL/RED WIRE REAR BODY FUSE BLOCK REAR SEAT HEATING CONTROL MODULE (UNDER LEFT REAR SEAT CUSHION) RED/WHT WIRE RIGHT REAR CUSHION SEAT HEATING ELEMENT RIGHT REAR HEATED, BACK SWITCH RR CUSHION NTC LO REF RR CUSHION NTC SIG RR HTD SEAT CUSHION ELEMENT CTRL RR HTD SEAT ELEMENT LO REF RR/ HTD/SEAT FUSE WHT/BLK WIRE YEL/WHT WIRE
