Lane departure warning circuit for Chevrolet Traverse II (2017-2021)

ACTIVE SAFETY CONTROL MODULE ALERT LED CTRL BATT POS VOLT BLK WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/PPL WIRE BODY CONTROL MODULE (FRONT OF CENTER CONSOLE) CHEVROLET CHEVROLET BUICK COLLISION ALERT INDICATORS COMPUTER DATA LINES SYSTEM CRUISE CTRL GAP UP/DOWN SW SIG DIMMING CTRL DRIVE MODE SELECT SWITCH EOCM SBZA FUSE FORWARD COLLISION WARNING SWITCH GMLAN SERIAL DATA (-) 8 GRN WIRE GRY WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/PPL WIRE GRY/WHT WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED HUD FUSE IGN 1 VOLT INDICATOR DIMMING CONTROL INSTRUMENT CLUSTER LANE DEP WARNING DISABLE SW SIG LANE DEP WARNING IND CTRL LANE DEPARTURE WARNING IND LANE DEPARTURE WARNING IND CTRL LANE DEPARTURE WARNING SWITCH LANE KEEPING ASSIST IND LEFT STEERING WHEEL CONTROLS SWITCH LIGHTING CTRL SW REF LO SPD GMLAN SER DATA LOGIC LOW SPD GMLAN SER DATA 2 LOW SPEED GMLAN SERIAL DATA PPL/GRY WIRE REAR BODY FUSE BLOCK RED/BRN WIRE SIG GND STEERING WHEEL AIR BAG COIL UNDERHOOD FUSE BLOCK W/ INTEGRATED BRAKE ASSIST W/O INTEGRATED BRAKE ASSIST WHT WIRE WHT/GRN WIRE WHT/GRY WIRE WINDSHIELD FRONT VIEW CAMERA (TOP CENTER OF WINDSHIELD) YEL WIRE
