Chevrolet Traverse II (2017-2021) steering column lock status sig Wiring diagrams

ACC IGN VOL ACC IGN VOLT ADAPTIVE CRUISE CTRL GAP UP/DOWN SW SIG AMBIENT LIGHT SENS SIG ANTI-LOCK BRAKES SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS ANTI-THEFT SYSTEM BATTERY POSITIVE VOLT BCM 1 FUSE BCM 2 FUSE BCM 3 FUSE BCM 4 FUSE BCM 6 FUSE BCM 7 FUSE BCM 8 FUSE BLK/BRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE APPLY SENS CTRL BRAKE APPLY SENS LOW REF BRAKE APPLY SENS SIG BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CHEVROLET BUICK COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM CRUISE CONTROL, EXTERIOR LIGHTS SYSTEMS CRUISE CONTROL, EXTERIOR LIGHTS, SHIFT INTERLOCK SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS DRV DR LOCK SW LOCK SIG DRV DR LOCK SW UNLOCK SIG DRV MODE 5 INDICATOR CTRL ELECTRONIC SUSPENSION SYSTEM ENGINE START/ STOP FRONT FOG LAMP SW SIG GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/WHT WIRE HAZARD SW LEFT TURN SIG HAZARD SW RIGHT TURN SIG HAZARD SW SIG HDLP AUTOMATIC HIGH BEAM DIM CTRL HDLP DIMMER SW HI BEAM SIG HDLP SW FLASH TO PASS SIG HORN SW SIG HDLP SW HDLP OFF SIG CTRL HDLP SW ON SIG HDLP SW PARK LAMPS SIG HEADLAMP HIGH BEAM CTRL HEADLIGHTS SYSTEM HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS HI SPD GMLAN SERIAL DATA (+) 1 REMOTE FUNCTION ACTUATOR RECEIVE SIG HI SPD GMLAN SERIAL DATA (-) (1) HORNS SYSTEM HOT AT ALL TIMES IGN MODE SW START LED SIG IGNITION MODE SW MODE VOL IGNITION MODE SWITCH INDICATOR DIMMING CTRL INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL LAMP DIM SW SIG INSTRUMENT PANEL LAMP DIMMER SW LOW REF IGN MODE SW ACC LED SIG INTERIOR LAMP DEFEAT SW SIG KEYLESS ENTRY CONTROL MODULE LED BACKLIGHT DIMMING CTRL LIGHTING CTRL SW REF LIN SERIAL DATA BUS 4 LOW SPD GMLAN SERIAL DATA PASSIVE START SW 2 LOW REF PASSIVE START SW SIG 2 REAR FOG LAMP SW SIG REAR WINDOW WIPER SW SIG RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE REMOTE FUNCTION ACTR CTRL REMOTE FUNCTION ACTR LOW REF REMOTE FUNCTION ACTR TRANSMIT SIGNAL RUN/CRANK IGN 1 VOLT SECURITY INDICATOR CTRL SET/COAST/RESUME/ ACCELERATE SW SIG WINDSHIELD WIPER SW LOW REF SHIFT INTERLOCK SYSTEM SHIFT SELECT SW PERFORMANCE SIG SIG GROUND STEERING COLUMN LOCK STATUS SIG TAP UP/TAP DOWN SW SIG TRACTION CTRL SW SIG 1 TRAILER BRAKE APPLY SIGNAL TRANSMISSIONS SYSTEM VIO/BLK WIRE VIO/BLU WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE WINDSHIELD WASHER SW SIG WINDSHIELD WIPER SW HI SIG WINDSHIELD WIPER SW LOW SIG WIPER/WASHER SYSTEM YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE

BATT POSITIVE VOLT BLK WIRE BLK/WHT WIRE BLU WIRE BLU/PPL WIRE BODY CONTROL MODULE (FRONT OF CENTER CONSOLE) COMPUTER DATA LINES SYSTEM DRIVER DOOR LATCH ASSEMBLY DRV DOOR OPEN SW SIG ESCL FUSE GRN WIRE GRN/PPL WIRE HI SPEED GMLAN SERIAL DATA (-) 1 HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL FUSE BLOCK KEYLESS ENTRY CONTROL MODULE LO SPD GMLAN SER DATA LO SPD GMLAN SERIAL DATA LOGIC OFF/ACCESSORY VOLT RED/GRY WIRE SIG GND STEERING COLUMN LOCK MODULE (TOP SIDE OF STEERING COLUMN) STEERING COLUMN LOCK STATUS SIG STR COL LCK STATUS SIG STR COL LOCK SIG UNDERHOOD FUSE BLOCK WHT WIRE WHT/YEL WIRE
