Chevrolet Traverse II (2017-2021) retained accessory power fuse ctrl Wiring diagram
This page shows the only wiring diagram for the component.retained accessory power fuse ctrl, which is found in the car Chevrolet Traverse II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram retained accessory power fuse ctrl (1 of 1)
BATT POSITIVE VOLT
BCM 3 FUSE
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (FRONT OF CENTER CONSOLE)
BRN WIRE
BRN/WHT WIRE
CAPTURE/COLUMN LOCK SHIFT POSITION SIG
CHEVROLET
COMPUTER DATA LINES SYSTEM
DISPLAY SIG TRANS SHIFT SELECTOR
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
ILL
INSTRUMENT PANEL FUSE BLOCK
LEFT TRANSMISSION MANUAL SHIFT SWITCH
LIN SERIAL DATA BUS 2
PARK LOCK SOLENOID CTRL
PARK POSITION SWITCH
POWER DISTRIBUTION SYSTEM
PPL
PPL/BLK WIRE
PPL/WHT WIRE
PPL/YEL WIRE
RAP RELAY SW CTRL
RED/GRY WIRE
RETAINED ACCESSORY POWER FUSE CTRL
RIGHT TRANSMISSION MANUAL SHIFT SWITCH
SIG GND
STEERING WHEEL AIR BAG COIL
TAP UP/TAP DOWN SW SIG
TRANSMISSION MANUAL SHIFT SWITCH TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/PPL WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> A/t circuit (2 of 4) -> RETAINED ACCESSORY POWER FUSE CTRL
