Chevrolet Traverse II (2017-2021) rear vertical down horizontal fwd Wiring diagram
This page shows the only wiring diagram for the component.rear vertical down horizontal fwd, which is found in the car Chevrolet Traverse II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear vertical down horizontal fwd (1 of 1)
BATT POS VOLT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT RECLINE MOTOR
DRVR PWR SEAT FUSE
FRONT VERTICAL DOWN
FRONT VERTICAL UP
FWD DN
GRN WIRE
GRY WIRE
HORIZONTAL RWD
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
PPL
REAR VERTICAL DOWN HORIZONTAL FWD
REAR VERTICAL UP
RECLINE FWD
RECLINE RWD
RED WIRE
RWD
YEL WIRE
Go to component -> Driver power seat circuit -> REAR VERTICAL DOWN HORIZONTAL FWD
