Chevrolet Traverse II (2017-2021) prk trlr lamp fuse Wiring diagram
This page shows the only wiring diagram for the component.prk trlr lamp fuse, which is found in the car Chevrolet Traverse II (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram prk trlr lamp fuse (1 of 1)
BACKUP LP RLY CTRL
BATT POS VOLT
BATTERY FUSE BLOCK
BCM 6 FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 5
GRN WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HI SPD GMLAN SER DATA (+) 1
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT TRAILER STOP/ TURN SIGNAL LAMP RELAY
LH TRAILER TURN SIG LAMP CTRL
PPL
PRK LAMP RLY CTRL
PRK TRLR LAMP FUSE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RH TRAILER TURN SIG LAMP CTRL
RIGHT TRAILER STOP/ TURN SIGNAL LAMP RELAY
SIG GND
TRAILER BACKUP LAMPS RELAY
TRAILER BRAKES PROVISION (BLUNT CUT) (LEFT SIDE OF DASH)
TRAILER BRK APPLY SIG
TRAILER CONNECTOR
TRAILER PARK LAMPS RELAY
TRLR BCK/UP FUSE
TRLR BRK FUSE
TRLR FUSE
TRLR ST/ TRN LT FUSE
TRLR ST/ TRN RT FUSE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit -> PRK TRLR LAMP FUSE
