Chevrolet Traverse II (2017-2021) driver ventilated switch Wiring diagrams
This page contains all the electrical diagrams for the component. driver ventilated switch, in which he is found in the car Chevrolet Traverse II (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver ventilated switch wiring diagram (1 of 2)
A/C COMPRESSOR (LOWER RIGHT FRONT SIDE OF ENGINE)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C COMPRESSOR COMPRESSOR SOLENOID VALVE
A/C ON IND
A/C ON SWITCH
AC CLTCH FUSE
AIR DELIVERY MODE CONTROL SWITCH
AUTO IND
AUTO SWITCH
AUX HEATER
AUXILIARY COOLANT PUMP RELAY
AUXILIARY HEATER COOLANT PUMP
AUXILIARY HVAC CONTROLS
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/YEL WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
CTRL
DATA BUS 9
DEFROST, LOWER AIR OUTLET IND
DOWN SWITCH
DRIVER HEATED/ BACK SWITCH
DRIVER VENTILATED SWITCH
ENG/COOL/ PMP FUSE
ENGINE CONTROLS IGNITION RELAY
FAN DOWN SWITCH
FAN SPEED HIGH SWITCH
FAN SPEED LOW SWITCH
FAN UP SWITCH
GMLAN SER DATA
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HIGH HEAT IND
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CONTROLS
HVAC FUSE
IGN 1 VOLT
ILL
LEFT REAR CUSHION/ BACK SWITCH
LEFT TEMPERATURE DOWN SWITCH
LOGIC
LOW HEAT IND
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH LEFT TEMPERATURE UP SWITCH
MED HEAT IND
NCA WIRE
PASSENGER HEATED/ BACK SWITCH
PASSENGER VENTILATED SWITCH
PPL
PPL/GRY WIRE
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BLU WIRE
RED/PPL WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR CUSHION/ BACK SWITCH
RIGHT TEMPERATURE DOWN SWITCH
RIGHT TEMPERATURE UP SWITCH
SIG GND
START STOP IND
START/STOP SWITCH
SYNC IND
SYNC SWITCH
TEMPERATURE
UNDERHOOD FUSE BLOCK
UP SWITCH
UPPER AIR OUTLET IND
WHT/GRY WIRE
WINDSHIELD DEFROST IND
YEL/BLU WIRE
Go to component -> Automatic a/c circuit (2 of 5) -> DRIVER VENTILATED SWITCH
driver ventilated switch wiring diagram (2 of 2)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACK SEAT BLOWER MOTOR
DRIVER CUSHION SEAT BLOWER MOTOR
DRIVER HEATED/ BACK SWITCH
DRIVER VENTILATED SWITCH
DRV SEAT VENT MOTOR CTRL 1
GRN WIRE
GRN/PPL WIRE
HIGH HEAT IND
HOT W/ IGNITION MAIN RELAY ENERGIZED
HVAC CONTROLS
LOGIC
LOW HEAT IND
LOW SPEED GMLAN SERIAL DATA
MED HEAT IND
NCA WIRE
PASS SEAT VENT MOTOR CTRL 1
PASSENGER BACK SEAT BLOWER MOTOR
PASSENGER CUSHION SEAT BLOWER MOTOR
PASSENGER HEATED/ BACK SWITCH
PASSENGER VENTILATED SWITCH
PPL/BLK WIRE
PPL/WHT WIRE
REAR BODY FUSE BLOCK
RUN/CRANK IGN 1 VOLT
VENT SEAT FUSE
Go to component -> Front heated seats circuit, w/ ventilation (2 of 2) -> DRIVER VENTILATED SWITCH
